Model
|
LSC | |||||
---|---|---|---|---|---|---|
Engine
|
9.5 OR 11.5 Gross Torque OHV
|
9.5 Gross Torque OHV
|
9.5 Gross Torque OHV
|
B&S OR HONDA
|
B&S 16.5 Gross Torque OHV
|
Briggs and Stratton XR2100
|
Engine CC’s
|
208 OR 249
|
208
|
208
|
250 – 270
|
420
|
420
|
Start
|
Manual
|
Manual
|
Manual
|
Manual or Electric
|
Electric
|
Electric
|
Acreage
|
<1 acre
|
<1 acre
|
<1 acre
|
1/2-4 acres
|
1/2-4 acres
|
4+ acres
|
Leaves
|
Yes
|
Yes
|
Yes
|
Yes
|
Yes
|
Yes
|
Kitchen Debris
|
No
|
No
|
Yes
|
Yes
|
Yes
|
Yes
|
Chipping Size
|
2-1/4”
|
2-1/4”
|
3″
|
3-1/2″
|
4″
|
4-1/2″
|
Shredding Hammers
|
None
|
None
|
16 Reversible
|
24 Reversible
|
36 Reversible
|
48 Reversible
|
Weight (lbs.)
|
140 – 160
|
128
|
152
|
235 – 275
|
337 – 444
|
700
|
Storage Space (L x Wheelbase X H)
|
53″ x 30″ x 27″
|
49″ x 24″ x 39″
|
38″ x 30″ x 43″
|
55″ x 37″ x 44″
|
61″ x 28″ x 48″
|
86″ x 53″ x 50″
|
MSRP*
|
$1,149 – $1,499
|
$1,349
|
$1,729
|
$2,499 – $3,599
|
$4,199 – $4,699
|
$5,999
|
|
Shredder-Chippers
Why a hammermill style shredder-chipper?
If your lawn and garden debris clean up requirements are more than processing mostly leaves and a few small twigs and branches, one of the MacKissic hammermill style shredder-chippers is certain to meet your needs and exceed your expectations.
The heart of the Mighty Mac shredder-chipper is the shredding chamber or hammermill. This hammermill houses free-swinging hammers that shred, tear, beat, and grind material until it is small enough to pass through the screen at the discharge end of the machine.
Our hammers are heat-treated and hardened, not sharpened or serrated like some others. This process, and the four cutting corners of each hammer will provide years of life before replacement is necessary.
We currently offer machines with hammermills that house 16, 24, 36, and 48 hammers. These hammers generate anywhere from 44,000 to over 114, 000 shredding hits per minute depending on the model. The key to successful shredding and chipping is the centrifugal force created by the weight of the flywheel and rotor. Our flywheel and rotor combinations range in weight from 24 lbs. in our smallest hammermill shredder-chipper to 148 lbs. in our largest.
The centrifugal clutch is another outstanding feature of our hammermill machines. They are designed to provide easy no-load starting and offer engine protection not found with a direct drive machine. The clutch will also disengage if the machine is overloaded. This allows the engine, flywheel, and rotor RPM’s to quickly recover to full speed and complete the task at hand.
With five sizes to choose from, MacKissic offers the right hammermill shredder-chipper to satisfy your needs.
Parts List and Schematics
Accessories
SC800 (Older Models: SC703/SC705/SC752/SC763) |
|||
Part Number
|
Description
|
Weight
|
MSRP*
|
---|---|---|---|
800-0015 | Standard replacement 1″ diameter hole screen | 3.3 lbs. | $105.00 |
800-0069 | Optional screen 1/4″ | 3 lbs. | $105.00 |
800-0049 | Optional screen 1/2″ | 3 lbs. | $105.00 |
800-0070 | Optional screen 3/4″ | 3 lbs. | $105.00 |
800-0011 | Optional oblong stamped bar screen (3″ x 1-1/2″ oblong openings) | 3 lbs. | $105.00 |
800-0060 | Optional rectangular welded bar screen (1-7/16″ x 4-15/16″ rectangular openings) | 4 lbs. | $145.00 |
800-0032 | Water resistant fitted cover | 1.3 lbs. | $85.00 |
800-0144 | Bagging kit | 5.6 lbs. | $135.00 |
800-0045 | Replacement bag only | 1 lbs. | $77.00 |
500-0013 | Leaf Tamper | 1 lbs. | $30.00 |
12P/PT/PTE
|
|||
Part Number
|
Description
|
Weight
|
MSRP*
|
---|---|---|---|
500-0004 | Standard replacement 1″ diameter hole screen | 4 lbs. | $145.00 |
500-0052 | Optional screen 1/4″ | 4.2 lbs. | $145.00 |
500-0053 | Optional screen 1/2″ | 4.2 lbs. | $145.00 |
500-0054 | Optional screen 3/4″ | 4.2 lbs. | $145.00 |
500-0055 | Optional oblong stamped bar screen (3″ x 1-1/2″ oblong openings) | 3.5 lbs. | $145.00 |
900-0133 | Optional rectangular welded bar screen (1-3/8″ x 7-1/8″ rectangular openings) | 5.2 lbs. | $176.00 |
108-0082 | Optional pull handle kit | 2 lbs. | $64.00 |
908-0055 | Water resistant fitted cover | 2 lbs. | $105.00 |
900-0116 | Bagging kit (12P/12PT/12PTE) | 4.5 lbs. | $145.00 |
800-0045 | Replacement bag only | 1 lbs. | $77.00 |
500-0013 | Leaf Tamper | 1 lbs. | $30.00 |
SC1650E and SC1650HTE (Older Models: SC150-12E/SC150HT-12E) |
|||
Part Number
|
Description
|
Weight
|
MSRP*
|
---|---|---|---|
910-0048 | Standard 1-1/4″ diameter hole screen | 5.5 lbs. | $198.00 |
910-0049 | Optional screen 1-1/2″ x 4-3/4″ slotted screen | 5.5 lbs. | $198.00 |
910-0064 | 3/4″ diameter hole screen | 5.5 lbs. | $198.00 |
913-0066 | Pull handle kit | 5 lbs. | $77.00 |
SC185 (Older Models: SC180/SC182/SC183) |
|||
Part Number
|
Description
|
Weight
|
MSRP*
|
---|---|---|---|
911-0007 | 1-1/4″ diameter hole screen | 8.2 lbs. | $265.00 |
911-0054 | Standard replacement bar screen | 10.5 lbs. | $265.00 |
911-0069 | Light kit | 2.5 lbs. | $105.00 |
911-0075 | Water resistant fitted cover | 2 lbs. | $125.00 |
911-0308 | 3/4″ diameter hole screen | 8.2 lbs. | $265.00 |
SC262 (Older Models: SC260) |
|||
Part Number
|
Description
|
Weight
|
MSRP*
|
---|---|---|---|
912-3530 | Light and fender kit | 50 lbs. | $269.00 |
912-2409 | Discharge screen, standard bar grate | 16 lbs. | $339.00 |
912-2410 | 3/4″ diameter hole screen | 5.5 lbs. | $299.00 |
912-3531 | Tongue Jack Caster | 15 lbs. | $49.00 |
Parts
Click for a SC800 parts list and exploded view. (pdf)
Click for a 12P parts list and exploded view. (pdf)
Click for a SC1650 parts list and exploded view. (pdf)
